Choose Input Hardness 選擇欲輸入硬度
HB 10m/m 3000kgf	HRC 150kgf	HS JIS	HV 50kgf

Hardness Conversion Table 輸入硬度表
/	HB	HRC	HS.	HV.
1	-	68	97	940
2	-	67.5	96	920
3	-	67	95	900
4	-	66.4	93	880
5	-	65.9	92	860
6	-	65.3	91	840
7	-	64.7	90	820
8	-	64	88	800
9	-	63.3	87	780
10	-	62.5	86	760
11	-	61.8	84	740
12	-	61	83	720
13	-	60.1	81	700
14	-	59.7	80.5	690
15	-	59.2	80	680
16	-	58.8	79.5	670
17	-	58.3	79	660
18	-	57.8	78	650
19	-	57.3	77	640
20	-	56.8	76	630
21	-	56.3	75	620
22	-	55.7	74.5	610
23	-	55.2	74	600
24	-	54.7	73	590
25	-	54.1	72	580
26	-	53.6	71.5	570
27	-	53	71	560
28	505	52.3	70	550
29	496	51.7	69	540
30	488	51.1	68	530
31	480	50.5	67	520
32	473	49.8	66.5	510
33	465	49.1	66	500
34	456	48.4	65	490
35	448	47.7	64	480
36	441	46.9	63	470
37	433	46.1	62	460
38	425	45.3	60.5	450
39	415	44.5	59	440
40	405	43.6	58	430

Hardness Conversion Table 輸入硬度表
/	HB	HRC	HS.	HV.
41	397	42.7	57	420
42	388	41.8	56	410
43	379	40.8	55	400
44	369	39.8	53.5	390
45	360	38.8	52	380
46	350	37.7	51	370
47	341	36.6	50	360
48	331	35.5	48.5	350
49	322	34.4	47	340
50	313	33.3	46	330
51	303	32.2	45	320
52	294	31	43.5	310
53	284	29.8	42	300
54	280	29.2	41.5	295
55	275	28.5	41	290
56	270	27.8	40.5	285
57	265	27.1	40	280
58	261	26.4	39	275
59	256	25.6	38	270
60	252	24.8	37.5	265
61	247	24	37	260
62	243	23.1	36.5	255
63	238	22.2	36	250
64	233	21.3	35	245
65	228	20.3	34	240
66	219	18	33	230
67	209	15.7	32	220
68	200	13.4	30	210
69	190	11	29	200
70	181	8.5	28	190
71	171	6	26	180
72	162	3	25	170
73	152	-	24	160
74	143	-	22	150
75	133	-	21	140
76	124	-	-	130
77	114	-	-	120
78	105	-	-	110
79	95	-	-	100
80	90	-	-	95
81	86	-	-	90
82	81	-	-	85
